- Particularly suitable for tapping
- Two-speed gearbox
- Right/left functionality and electronic speed adjustment
- Heat protection
- Morse Taper 2 spindle with integrated tool cooling and lubrication
- High precision height adjustment for:
- Low maintenance
- Minimal wear correction
- Strong dual coil CNC machined magnet
Technical data |
Annular cutting |
Ø 12 - 55 mm |
Twist drilling |
Ø 1 - 23 mm |
Countersinking |
Ø 10 - 60 mm |
Threading |
M3 - M20 |
Length |
320 mm |
Width |
200 mm |
Height |
490 - 660 mm |
Stroke |
170 mm |
Weight |
13,75 kg |
Magnet (l x w x h) |
168 x 84 x 49 mm |
Magnetic force |
1850 kg |
Motor power |
1600 W |
Total power |
1700 W |
Speed (no load) |
(I) 60 - 275 rpm |
|
(II) 100 - 500 rpm |
Speed (load 1600 W) |
(I) 60 - 275 rpm |
|
(II) 100 - 500 rpm |
Spindle (Weldon) |
MT3 19,05 mm |
Voltage |
110 - 120 V / 60 Hz |
|
220 - 240 V / 50 - 60 Hz |
