Magnetic Drilling Machine ECO.200
Magnetic Drilling Machine ECO.200
Magnetic Drilling Machine ECO.200
Magnetic Drilling Machine ECO.200

Magnetic Drilling Machine ECO.200


Please contact us if you are interested in this product.


  • Two-speed gearbox

  • Integrated tool cooling and lubrication tank and fluid level indication
  • Integrated safety strap and lifting shackle

  • High precision tubular rail balancer system

  • Progressive feed assist

  • Morse Taper 4 spindle

  • Strong triple coil CNC machined magnet
Technical data
Annular cutting Ø 12 - 200 mm
Twist drilling Ø 1 - 44 mm
Countersinking Ø 10 - 205 mm
Length 480 mm
Width 260 mm
Height 660 - 840 mm
Stroke 180 mm
Weight 53 kg
Magnet (l x w x h) 330 x 110 x 63 mm
Magnetic force 3900 kg
Motor power 3600 W
Total power 3800 W
Speed (no load) (I) 70 - 150 rpm
  (II) 170 - 410 rpm
Speed (load 3600 W ) (I) 70 - 150 rpm
  (II) 170 - 410 rpm
Spindle (Weldon) MT4 31,75 mm
Voltage 110 - 120 V / 60 Hz


220 - 240 V / 50 - 60 Hz
