| Optimum Focus Distance |
70 meters |
230 feet |
| Lens Operating Range |
Hand-held |
15 - 80 meters (50 - 262 feet) |
| Tripod mounted |
15 - 90 meters (50 - 295 feet) |
| Speed Accuracy |
± 2 km/h |
± 1 mph |
| Speed Range |
0 km/h to 320 km/h |
0 mph to 200 mph |
| Distance Accuracy |
±30 cm absolute accuracy |
± 12 inches absolute accuracy |
| Display Resolution |
Speed |
1 km/h : 1 mph |
| |
Distance |
1 meter : 1 foot |
| Measurement Time |
|
0.33 - 0.67 second |
| Units of Measure |
Speed |
kilometers per hour |
| miles per hour |
| Distance |
meters |
| feet |
| Laser Wavelength |
905 nanometers nominal |
|
| Beam Divergence |
2.5 milliradians nominal |
|
| Eye Safety |
FDA Class 1 (CFR 21) |
IEC 60825-1 |
| Body |
Inner Structure: Aluminium |
outer shell: composite polycarbonate |
| Environment |
IP65-IP67 |
Water and Dust Resistant |
| Temperature Range |
Operating |
-10°C to +60° C (14°F to 140°F) |
| Charging |
0°C to +45°C (32°F to +113°F) |
| Storage |
-20° C to +60°C (-4°F to 140°F) |
| Capture Data Storage |
Removable SD Card |
4 GB and greater |
| Operation system |
|
Linux based |
| Display |
4.3 inch (10.9 cm), 480x272 pixel, color, 18 bits per pixel (bpp), touch sensitive |
| Camera Sensor |
2.0 MPixel (1600x1200) |
|
| Camera Lens |
75 mm, manual focus and iris |
|
| Battery Pack |
7.4 v dc, Lithium-ion Polymer rechargeable battery pack, short circuit and overcharge protected, providing up to 8 hours of cordless operation |
| Video Modes |
Selectable video capture frame rate before the measurement and based on motion clip:640*480/13FPS |
| Still Image Sizes |
1600x1200 pixels |
| Measure Mode: |
Continuous,Locking,Automatic,Video Tracking,Single Distance Measure,Gate Mode |
| Languages: |
English |
|
| Warranty: |
18 month |
|
